Consumibles para una preparación perfecta de muestras metalográficas

Con QPREP, QATM ofrece una amplia gama de consumibles de alta calidad para la preparación y el análisis de muestras metalográficas. Todos los productos se someten a pruebas exhaustivas en nuestro laboratorio central y se seleccionan para una interacción óptima con los aparatos QATM.

¡Solicite una oferta gratis y sin compromiso!

Marque los artículos que desea agregar a la lista de solicitud de oferta. Usted puede seleccionar artículos en cualquier página de producto. Después de haber añadido un artículo, aparece la lista de solicitud en la esquina derecha superior de la página.

Solicitud general

¿No está seguro de qué artículos necesita o prefiere un presupuesto general?

Enviar una solicitud general

Area
Category
Type
Abrasive material
Diameter
Grit
Fixation
Bundle
Reset search

Dia-COMPLETE Poly,
All-In-One diamond suspension

Combined product of diamond suspension and lubricant

Grain Size

95011833

0.25 µm

500 ml

95011839

0.25 µm

1 l

95011845

0.25 µm

2.5 l

95016023

0.25 µm

5 l

95011834

1 µm

500 ml

95011840

1 µm

1 l

95011846

1 µm

2.5 l

95015394

1 µm

5 l

95011835

3 µm

500 ml

95011841

3 µm

1 l

95011847

3 µm

2.5 l

95015395

3 µm

5 l

95011836

6 µm

500 ml

95011842

6 µm

1 l

95011848

6 µm

2.5 l

95015396

6 µm

5 l

95011837

9 µm

500 ml

95011843

9 µm

1 l

95011849

9 µm

2.5 l

95015397

9 µm

5 l

95011844

15 µm

1 l

Dia-COMPLETE Mono,
All-In-One diamond suspension

Combined product of diamond suspension and lubricant

Grain Size

95011815

1 µm

500 ml

95011820

1 µm

1 l

95011825

1 µm

2.5 l

95015404

1 µm

5 l

95011816

3 µm

500 ml

95011821

3 µm

1 l

95011826

3 µm

2.5 l

95015405

3 µm

5 l

95011817

6 µm

500 ml

95011822

6 µm

1 l

95011827

6 µm

2.5 l

95015406

6 µm

5 l

95011818

9 µm

250 ml

95011823

9 µm

500 ml

95011828

9 µm

1 l

95015407

9 µm

2.5 l

Diamond suspension polycrystalline

Grain Size

92002353

1 µm

250 ml

95016017

1 µm

500 ml

92004798

1 µm

1 l

95002761

1 µm

2.5 l

95014519

1 µm

5 l

92002354

3 µm

250 ml

95016018

3 µm

500 ml

92004799

3 µm

1 l

95002762

3 µm

2.5 l

95014520

3 µm

5 l

92002355

6 µm

250 ml

95016019

6 µm

500 ml

92004800

6 µm

1 l

95002763

6 µm

2.5 l

95014521

6 µm

5 l

92002356

9 µm

250 ml

95016020

9 µm

500 ml

92004801

9 µm

1 l

95002764

9 µm

2.5 l

95014522

9 µm

5 l

95005738

15 µm

1 l

Diamond suspension monocrystalline

Grain Size

92002346

1 µm

250 ml

95016012

1 µm

500 ml

92004791

1 µm

1 l

95002755

1 µm

2.5 l

95014514

1 µm

5 l

92002347

3 µm

250 ml

95016013

3 µm

500 ml

92004792

3 µm

1 l

95002756

3 µm

2.5 l

95014515

3 µm

5 l

92002348

6 µm

250 ml

95016014

6 µm

500 ml

92004793

6 µm

1 l

95002757

6 µm

2.5 l

95014516

6 µm

5 l

92002349

9 µm

250 ml

95016015

9 µm

500 ml

92004794

9 µm

1 l

95002758

9 µm

2.5 l

95014517

9 µm

5 l

Diamond suspension (alcohol-based)
polycrystalline

Grain Size

95003494

1 µm

1 l

95003495

3 µm

1 l

95003496

6 µm

1 l

95003497

9 µm

1 l

95007978

15 µm

1 l

Diamond suspension (alcohol-based)
monocrystalline

Grain Size (µm)

95003490

1 µm

1 l

95003491

3 µm

1 l

95003492

6 µm

1 l

95003493

9 µm

1 l

Diamond suspension (oil-based)
polycrystalline

Grain Size

95002792

1 µm

1 pc

95002793

3 µm

1 pc

95002794

6 µm

1 pc

95002795

9 µm

1 pc

Accesorios

Spray nozzle

• for diamond suspensions of all grain sizes
• for 250 ml, 500 ml and 1 L bottles

95016723 Spray nozzle

Qdoser ONE dosing system for suspensions

Qdoser ONE basic module

Z5631014 Qdoser ONE holder

Z5631016 Qdoser ONE stand

Diamond spray polycrystalline

CFC-free

Grain Size

95016244

0.25 µm

200 ml

95016025

1 µm

200 ml

95016026

3 µm

200 ml

95016027

6 µm

200 ml

95016028

9 µm

200 ml

95016245

15 µm

200 ml

Diamond paste polycrystalline

10 g syringe

Grain Size

92002339

0.25 μm

10 g

92002340

1 µm

10 g

92002341

3 µm

10 g

92002342

6 µm

10 g

92002343

9 µm

10 g

92002344

15 µm

10 g

Diamond paste monocrystalline

10 g syringe

Grain Size

92002365

0.25 µm

10 g

92002333

1 µm

10 g

92002316

3 µm

10 g

92002335

6 µm

10 g

92002336

9 µm

10 g

92002337

15 µm

10 g

Diamond stick monocrystalline

• diamond wax
• to be used with lubricant

Grain Size (µm)

95015386

1 µm

10 g

95015387

3 µm

10 g

95015388

6 µm

10 g

95015389

9 µm

10 g

Diamond lubricant, additive for diamond suspension/paste

Color

Characteristics

92005509

Yellow

- water-based -

ecologically friendly

1 l

92004925

Yellow

- water-based -

ecologically friendly

2.5 l

92005510

Yellow

- water-based -

ecologically friendly

5 l

95016174

Yellow

- water-based -

ecologically friendly

10 l

95000901

Blue

- alcohol-based -

for water-free preparation

1 l

95000911

Blue

- alcohol-based -

for water-free preparation

2,5 l

95001194

Blue

- alcohol-based -

for water-free preparation

5 l

95001759

Red

- oil-based -

for water-free preparation

1 l

95001772

Red

- oil-based -

for water-free preparation

2.5 l

95001784

Red

- oil-based -

for water-free preparation

5 l

Diamond lubrication concentrate

• for manual dosing with diamond suspension

Color, Characteristics

95016362 Blue, - for alcohol-based lubricant -
for 10 L lubricant, mix with 9 parts of ethanol, , , 1 l

Ethanol

95004662

Ethanol, 99% denatured

1 l

95004663

Ethanol, 99% denatured

5 l

95004664

Ethanol, 99% denatured

10 l

Fine polishing suspensions

Fine polishing suspension (Al2O3)
• does not crystallize
•for ferrous materials, polymers, composites, PCB, rocks and minerals

Description

ph-value

Grain Size

92002534

Eposal

pH≈8.0

0.06 µm

1 l

Colloidal silica
• for polishing, also mixable with diluted etchant
•

Description

ph-value

Grain Size

92002536

Eposil F

pH≈9.5

0.1 µm

1 l

95013858

Eposil Non Dry

pH≈9.5

0.05 µm

1 l

95013958

Eposil Non Dry

pH≈9.5

0.05 µm

10 l

92002541

Eposil M

pH≈9.5

0.06 µm

1 l

Colloidal silica
• for titanium, nickel, tin and its alloys

Description

ph-value

Grain Size

95001206

Eposil M11

pH≈11.0

0.06 µm

1 l

Water-free fine polishing suspension
• e.g. for magnesium, zinc

Description

ph-value

Grain Size

95005033

Etosil E

pH≈7.0

0.06 µm

1 l

Alumina suspension, calcinated

Aqueous concentrate, to dilute, 3-5 part of dest. water

Description

Grain Size

92002533

Alumina suspension

0.3 µm

1 l

92002532

Alumina suspension

0.6 µm

1 l

92004950

Alumina suspension

1 µm

1 l

Magnetic foil, self-adhesive

Magnetic foil, normal adhesion
• to apply on working wheel

Ø

Thickness

92008528

200 mm

1 mm

1 pc

92005820

250 mm

1 mm

1 pc

92005822

300 mm

1 mm

1 pc

Magnetic foil, strong adhesion
• to apply on working wheel

Ø

Thickness

95016345

200 mm

1 mm

1 pc

95016346

250 mm

1 mm

1 pc

95012161

300 mm

1 mm

1 pc

95014137

350 mm

1 mm

1 pc

Magnetic foil, strongest adhesion
• to apply on working wheel-HR-• increased magnetic adhesion by higher material thickness

Ø

Thickness

95016298

200 mm

2 mm

1 pc

95016300

250 mm

2 mm

1 pc

95016301

300 mm

2 mm

1 pc

95016302

350 mm

2 mm

1 pc

GALAXY Polishing cloth with metal back

GALAXY – ALPHA
• Suitable for pre-polishing
• Very hard, perforated chemical fiber cloth
• For ceramics, hard metal, steel, grey cast iron, aluminum
• High lifetime and stock removal
• For use with diamond grain size: 15/9 µm
• Fixation system: Magnetic foil

Description

Ø

95001407

ALPHA

200 mm

5 pcs

95001408

ALPHA

250 mm

5 pcs

95001409

ALPHA

300 mm

5 pcs

95013994

ALPHA

350 mm

5 pcs

GALAXY – BETA
• Suitable for pre-polishing
• Hard synthetic cloth
• Materials with high hardness, steel, grey cast iron, hard metal, ceramics
• For use with diamond grain size: 15/9/6 µm
• Fixation system: Magnetic foil

Description

Ø

Fixation

95001410

BETA

200 mm

5 pcs

95001411

BETA

250 mm

5 pcs

95001412

BETA

300 mm

5 pcs

95013995

BETA

350 mm

5 pcs

GALAXY – DELTA
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, plastics [CFK, GFK], coatings, aluminum
• For use with diamond grain size: 9/6/3 µm
• Fixation system: Magnetic foil

Description

Ø

95001413

DELTA

200 mm

5 pcs

95001414

DELTA

250 mm

5 pcs

95001415

DELTA

300 mm

5 pcs

95013996

DELTA

350 mm

5 pcs

GALAXY - GAMMA
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, coatings, plastics [CFK, GFK]
• For use with diamond grain size: 9/6/3 µm
• Fixation system: Magnetic foil

Description

Ø

95017588

GAMMA

200 mm

5 pcs

95017589

GAMMA

250 mm

5 pcs

95017590

GAMMA

300 mm

5 pcs

GALAXY – PHI
• Suitable for pre-, intermediate-, and end polishing
• Medium hard chemical fiber cloth
• For iron, non – ferrous metals, minerals, ceramics, composite materials
• For use with diamond grain size: 9/6/3/1 µm
• Fixation system: Magnetic foil

Description

Ø

95012739

PHI

200 mm

5 pcs

95012740

PHI

250 mm

5 pcs

95012741

PHI

300 mm

5 pcs

95014002

PHI

350 mm

5 pcs

GALAXY – SIGMA
• Suitable for intermediate and end polishing
• Soft wool cloth
• For all materials
• For use with diamond grain size: 6/3/1 µm
• Fixation system: Magnetic foil

Description

Ø

95001416

SIGMA

200 mm

5 pcs

95001417

SIGMA

250 mm

5 pcs

95001418

SIGMA

300 mm

5 pcs

95013997

SIGMA

350 mm

5 pcs

GALAXY – ETA
• Suitable for end polishing
• Short flocked, medium hard synthetic cloth
• For all materials of medium and high hardness
• For use with diamond grain size: 3/1 µm
• Fixation system: Magnetic foil

Description

Ø

95016832

ETA

200 mm

5 pcs

95016833

ETA

250 mm

5 pcs

95016834

ETA

300 mm

5 pcs

95016835

ETA

350 mm

5 pcs

GALAXY – IOTA
• Suitable for end polishing as well as fine polishing with fine polishing suspension
• Short flocked, soft synthetic cloth
• For all materials, especially hard materials
• For use with diamond grain size: 3/1 µm
•, Suitable for oxide suspensions
•, Fixation system: Magnetic foil

Description

Ø

95001419

IOTA

200 mm

5 pcs

95001420

IOTA

250 mm

5 pcs

95001421

IOTA

300 mm

5 pcs

95013998

IOTA

350 mm

5 pcs

GALAXY – ZETA
• Suitable for end polishing as well as fine polishing with fine polishing suspension
• Short flocked, soft synthetic cloth
• For all materials
• For use with diamond grain size: 3/1 µm
•, Suitable for oxide suspensions as well as alumina
• Fixation system: Magnetic foil

Description

Ø

95005776

ZETA

200 mm

5 pcs

95005777

ZETA

250 mm

5 pcs

95005778

ZETA

300 mm

5 pcs

95013999

ZETA

350 mm

5 pcs

GALAXY – OMEGA
• Suitable for fine polishing with fine polishing suspension
• Soft synthetic cloth (chemical resistant)
•, For all materials
•, Suitable for oxide suspensions
• Fixation system: Magnetic foil

Description

Ø

95005779

OMEGA

200 mm

5 pcs

95005780

OMEGA

250 mm

5 pcs

95005781

OMEGA

300 mm

5 pcs

95014000

OMEGA

350 mm

5 pcs

GALAXY – LAMBDA-HR-• Suitable for fine polishing with fine polishing suspension-HR-• Brushed, structured synthetic cloth (chemical resistant)-HR-• For all materials-HR-•, Suitable for oxide suspensions as well as alumina-HR-• Fixation system: Magnetic foil

Description

Ø

95005782

LAMBDA

200 mm

5 pcs

95005783

LAMBDA

250 mm

5 pcs

95005784

LAMBDA

300 mm

5 pcs

95014001

LAMBDA

350 mm

5 pcs

X-Tap

X-Tap (self-adhesive to stick on the working wheel)

Ø

95017015

200 mm

1 pc

95017016

250 mm

1 pc

95017017

300 mm

1 pc

95017018

350 mm

1 pc

GALAXY-X-Tap (for using with magnetic foil)

Ø

95017019

200 mm

1 pc

95017020

250 mm

1 pc

95017021

300 mm

1 pc

95017022

350 mm

1 pc

Polishing cloths, self-adhesive

ALPHA – Polishing cloth
• Suitable for pre-polishing
• Very hard, perforated chemical fiber cloth
• For ceramics, hard metal, steel, grey cast iron, aluminum
• High lifetime and stock removal
• For use with diamond grain size: 15/9 µm
• Fixation system: X-Tap

Description

Ø

92002555

ALPHA

200 mm

5 pcs

92002564

ALPHA

250 mm

5 pcs

92002573

ALPHA

300 mm

5 pcs

95016029

ALPHA

350 mm

5 pcs

BETA – Polishing cloth-HR-• Suitable for pre-polishing-HR-• Hard synthetic cloth-HR-• Materials with high hardness, steel, grey cast iron, hard metal, ceramics-HR-• For use with diamond grain size: 15/9/6 µm-HR-• Fixation system: X-Tap

Description

Ø

Fixation

95006571

BETA

200 mm

5 pcs

95006572

BETA

250 mm

5 pcs

95006573

BETA

300 mm

5 pcs

95016030

BETA

350 mm

5 pcs

DELTA – Polishing cloth
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, plastics [CFK, GFK], coatings, aluminum
• For use with diamond grain size: 9/6/3 µm
• Fixation system: X-Tap

Description

Ø

92008801

DELTA

200 mm

5 pcs

92008802

DELTA

250 mm

5 pcs

92008803

DELTA

300 mm

5 pcs

95016034

DELTA

350 mm

5 pcs

GAMMA – Polishing cloth
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, coatings, plastics [CFK, GFK],
• For use with diamond grain size: 9/6/3 µm
• Fixation system: X-Tap

Description

Ø

92002558

Gamma

200 mm

5 pcs

92002567

Gamma

250 mm

5 pcs

92002576

Gamma

300 mm

5 pcs

95016032

Gamma

350 mm

5 pcs

PHI – Polishing cloth
• Suitable for pre-, intermediate-, and end polishing
• Medium hard chemical fiber cloth
• For iron, non – ferrous metals, minerals, ceramics, composite materials
• For use with diamond grain size: 9/6/3/1 µm
• Fixation system: X-Tap

Description

Ø

92005678

PHI

200 mm

5 pcs

92005679

PHI

250 mm

5 pcs

92005680

PHI

300 mm

5 pcs

95016031

PHI

350 mm

5 pcs

SIGMA – Polishing cloth
• Suitable for pre- & intermediate polishing
• Soft wool cloth
• For all materials
• For use with diamond grain size: 6/3/1 µm
• Fixation system: X-Tap

Description

Ø

92008810

SIGMA

200 mm

5 pcs

92008811

SIGMA

250 mm

5 pcs

92008812

SIGMA

300 mm

5 pcs

95016033

SIGMA

350 mm

5 pcs

ETA – Polishing cloth
• Suitable for end polishing
• Short flocked, medium hard synthetic cloth
• For all materials of medium and high hardness
• For use with diamond grain size: 3/1 µm
• Fixation system: X-Tap

Description

Ø

95016828

ETA

200 mm

5 pcs

95016829

ETA

250 mm

5 pcs

95016830

ETA

300 mm

5 pcs

95016831

ETA

350 mm

5 pcs

IOTA – Polishing cloth
• Suitable for end polishing as well as fine polishing with fine polishing suspension
• Short flocked, soft synthetic cloth
• for all materials, especially hard materials
• For use with diamond grain size: 3/1 µm
• Suitable for oxide suspensions
• Fixation system: X-Tap

Description

Ø

95002393

IOTA

200 mm

5 pcs

95002394

IOTA

250 mm

5 pcs

95002395

IOTA

300 mm

5 pcs

95016036

IOTA

350 mm

5 pcs

ZETA – Polishing cloth
• Suitable for end polishing as well as fine polishing with fine polishing suspension
• Short flocked, soft synthetic cloth
• for all materials
• For use with diamond grain size: 3/1 µm
• Suitable for oxide suspensions as well as alumina
• Fixation system: X-Tap

Description

Ø

92005681

ZETA

200 mm

5 pcs

92005683

ZETA

250 mm

5 pcs

92005684

ZETA

300 mm

5 pcs

95016037

ZETA

350 mm

5 pcs

KAPPA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Soft polishing felt
• For all materials
• Suitable for alumina
• Fixation system: X-Tap

Description

Ø

92002563

Kappa

200 mm

5 pcs

92002572

Kappa

250 mm

5 pcs

92002581

Kappa

300 mm

5 pcs

95016038

Kappa

350 mm

5 pcs

OMEGA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Soft synthetic cloth (chemical resistant)
• For all materials
• Suitable for oxide suspensions
• Fixation system: X-Tap

Description

Ø

92002562

OMEGA

200 mm

5 pcs

92002571

OMEGA

250 mm

5 pcs

92002580

OMEGA

300 mm

5 pcs

95016039

OMEGA

350 mm

5 pcs

LAMBDA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Brushed, structured synthetic cloth (chemical resistant)
• For all materials
• Suitable for oxide suspensions as well as alumina
• Fixation system: X-Tap

Description

Ø

Fixation

95003597

LAMBDA

200 mm

5 pcs

95003598

LAMBDA

250 mm

5 pcs

95003599

LAMBDA

300 mm

5 pcs

95016040

LAMBDA

350 mm

5 pcs

all polishing cloths also available for Qpol 30 (Ø 30 mm)

Media carrier plate

• for grinding and polishing robot Qpol 250 BOT (SAPHIR X-Change)

Ø

95005867

250 mm

1 pc

Filter inserts

Filter inserts for settling tank
(until year of construction 2012)

Dimensions

Mesh size

95017310

Fleece

290 x 150 x 190 mm

40 µm

95017311

Fleece

290 x 150 x 190 mm

60 µm

Filter inserts for settling tank
(from year of construction 2013)

Dimensions

Mesh size

95017312

Fleece

250 x 200 x 155 mm

60 µm

95017313

Fleece

250 x 200 x 155 mm

100 µm

Consumibles para una preparación perfecta de muestras metalográficas

¡Solicite una oferta gratis y sin compromiso!

Solicitud general

Dia-COMPLETE Poly, All-In-One diamond suspension

Dia-COMPLETE Mono, All-In-One diamond suspension

Diamond suspension polycrystalline

Diamond suspension monocrystalline

Diamond suspension (alcohol-based) polycrystalline

Diamond suspension (alcohol-based) monocrystalline

Diamond suspension (oil-based) polycrystalline

Accesorios

Spray nozzle

Qdoser ONE dosing system for suspensions

Diamond spray polycrystalline

Diamond paste polycrystalline

Diamond paste monocrystalline

Diamond stick monocrystalline

Diamond lubricant, additive for diamond suspension/paste

Diamond lubrication concentrate

Ethanol

Fine polishing suspensions

Fine polishing suspension (Al2O3)• does not crystallize•for ferrous materials, polymers, composites, PCB, rocks and minerals

Colloidal silica• for polishing, also mixable with diluted etchant•

Colloidal silica• for titanium, nickel, tin and its alloys

Water-free fine polishing suspension• e.g. for magnesium, zinc

Alumina suspension, calcinated

Magnetic foil, self-adhesive

Magnetic foil, normal adhesion• to apply on working wheel

Magnetic foil, strong adhesion• to apply on working wheel

Magnetic foil, strongest adhesion• to apply on working wheel-HR-• increased magnetic adhesion by higher material thickness

GALAXY Polishing cloth with metal back

GALAXY – ALPHA • Suitable for pre-polishing• Very hard, perforated chemical fiber cloth• For ceramics, hard metal, steel, grey cast iron, aluminum• High lifetime and stock removal• For use with diamond grain size: 15/9 µm• Fixation system: Magnetic foil

GALAXY – BETA• Suitable for pre-polishing• Hard synthetic cloth• Materials with high hardness, steel, grey cast iron, hard metal, ceramics• For use with diamond grain size: 15/9/6 µm• Fixation system: Magnetic foil

GALAXY – DELTA• Suitable for pre- & intermediate polishing• Medium hard silk cloth• C-steels, precious metal, plastics [CFK, GFK], coatings, aluminum• For use with diamond grain size: 9/6/3 µm• Fixation system: Magnetic foil

GALAXY - GAMMA• Suitable for pre- & intermediate polishing• Medium hard silk cloth• C-steels, precious metal, coatings, plastics [CFK, GFK] • For use with diamond grain size: 9/6/3 µm• Fixation system: Magnetic foil

GALAXY – PHI• Suitable for pre-, intermediate-, and end polishing• Medium hard chemical fiber cloth• For iron, non – ferrous metals, minerals, ceramics, composite materials• For use with diamond grain size: 9/6/3/1 µm• Fixation system: Magnetic foil

GALAXY – SIGMA• Suitable for intermediate and end polishing• Soft wool cloth• For all materials• For use with diamond grain size: 6/3/1 µm• Fixation system: Magnetic foil

GALAXY – ETA • Suitable for end polishing• Short flocked, medium hard synthetic cloth• For all materials of medium and high hardness• For use with diamond grain size: 3/1 µm• Fixation system: Magnetic foil

GALAXY – ZETA• Suitable for end polishing as well as fine polishing with fine polishing suspension• Short flocked, soft synthetic cloth• For all materials• For use with diamond grain size: 3/1 µm•, Suitable for oxide suspensions as well as alumina• Fixation system: Magnetic foil

GALAXY – OMEGA• Suitable for fine polishing with fine polishing suspension• Soft synthetic cloth (chemical resistant)•, For all materials•, Suitable for oxide suspensions• Fixation system: Magnetic foil

GALAXY – LAMBDA-HR-• Suitable for fine polishing with fine polishing suspension-HR-• Brushed, structured synthetic cloth (chemical resistant)-HR-• For all materials-HR-•, Suitable for oxide suspensions as well as alumina-HR-• Fixation system: Magnetic foil

X-Tap

X-Tap (self-adhesive to stick on the working wheel)

GALAXY-X-Tap (for using with magnetic foil)

Polishing cloths, self-adhesive

ALPHA – Polishing cloth• Suitable for pre-polishing• Very hard, perforated chemical fiber cloth• For ceramics, hard metal, steel, grey cast iron, aluminum• High lifetime and stock removal• For use with diamond grain size: 15/9 µm• Fixation system: X-Tap

BETA – Polishing cloth-HR-• Suitable for pre-polishing-HR-• Hard synthetic cloth-HR-• Materials with high hardness, steel, grey cast iron, hard metal, ceramics-HR-• For use with diamond grain size: 15/9/6 µm-HR-• Fixation system: X-Tap

DELTA – Polishing cloth• Suitable for pre- & intermediate polishing• Medium hard silk cloth• C-steels, precious metal, plastics [CFK, GFK], coatings, aluminum• For use with diamond grain size: 9/6/3 µm• Fixation system: X-Tap

GAMMA – Polishing cloth• Suitable for pre- & intermediate polishing• Medium hard silk cloth• C-steels, precious metal, coatings, plastics [CFK, GFK], • For use with diamond grain size: 9/6/3 µm• Fixation system: X-Tap

PHI – Polishing cloth• Suitable for pre-, intermediate-, and end polishing• Medium hard chemical fiber cloth• For iron, non – ferrous metals, minerals, ceramics, composite materials• For use with diamond grain size: 9/6/3/1 µm• Fixation system: X-Tap

SIGMA – Polishing cloth• Suitable for pre- & intermediate polishing• Soft wool cloth• For all materials• For use with diamond grain size: 6/3/1 µm• Fixation system: X-Tap

ETA – Polishing cloth• Suitable for end polishing• Short flocked, medium hard synthetic cloth• For all materials of medium and high hardness• For use with diamond grain size: 3/1 µm• Fixation system: X-Tap

ZETA – Polishing cloth• Suitable for end polishing as well as fine polishing with fine polishing suspension• Short flocked, soft synthetic cloth• for all materials• For use with diamond grain size: 3/1 µm• Suitable for oxide suspensions as well as alumina• Fixation system: X-Tap

KAPPA – Polishing cloth• Suitable for fine polishing with fine polishing suspension• Soft polishing felt• For all materials• Suitable for alumina• Fixation system: X-Tap

OMEGA – Polishing cloth• Suitable for fine polishing with fine polishing suspension• Soft synthetic cloth (chemical resistant)• For all materials• Suitable for oxide suspensions• Fixation system: X-Tap

LAMBDA – Polishing cloth• Suitable for fine polishing with fine polishing suspension• Brushed, structured synthetic cloth (chemical resistant)• For all materials• Suitable for oxide suspensions as well as alumina• Fixation system: X-Tap

Media carrier plate

Filter inserts

Filter inserts for settling tank (until year of construction 2012)

Filter inserts for settling tank (from year of construction 2013)

Dia-COMPLETE Poly,
All-In-One diamond suspension

Dia-COMPLETE Mono,
All-In-One diamond suspension

Diamond suspension (alcohol-based)
polycrystalline

Diamond suspension (alcohol-based)
monocrystalline

Diamond suspension (oil-based)
polycrystalline

Fine polishing suspension (Al2O3)
• does not crystallize
•for ferrous materials, polymers, composites, PCB, rocks and minerals

Colloidal silica
• for polishing, also mixable with diluted etchant
•

Colloidal silica
• for titanium, nickel, tin and its alloys

Water-free fine polishing suspension
• e.g. for magnesium, zinc

Magnetic foil, normal adhesion
• to apply on working wheel

Magnetic foil, strong adhesion
• to apply on working wheel

Magnetic foil, strongest adhesion
• to apply on working wheel-HR-• increased magnetic adhesion by higher material thickness

GALAXY – ALPHA
• Suitable for pre-polishing
• Very hard, perforated chemical fiber cloth
• For ceramics, hard metal, steel, grey cast iron, aluminum
• High lifetime and stock removal
• For use with diamond grain size: 15/9 µm
• Fixation system: Magnetic foil

GALAXY – BETA
• Suitable for pre-polishing
• Hard synthetic cloth
• Materials with high hardness, steel, grey cast iron, hard metal, ceramics
• For use with diamond grain size: 15/9/6 µm
• Fixation system: Magnetic foil

GALAXY – DELTA
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, plastics [CFK, GFK], coatings, aluminum
• For use with diamond grain size: 9/6/3 µm
• Fixation system: Magnetic foil

GALAXY - GAMMA
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, coatings, plastics [CFK, GFK]
• For use with diamond grain size: 9/6/3 µm
• Fixation system: Magnetic foil

GALAXY – PHI
• Suitable for pre-, intermediate-, and end polishing
• Medium hard chemical fiber cloth
• For iron, non – ferrous metals, minerals, ceramics, composite materials
• For use with diamond grain size: 9/6/3/1 µm
• Fixation system: Magnetic foil

GALAXY – SIGMA
• Suitable for intermediate and end polishing
• Soft wool cloth
• For all materials
• For use with diamond grain size: 6/3/1 µm
• Fixation system: Magnetic foil

GALAXY – ETA
• Suitable for end polishing
• Short flocked, medium hard synthetic cloth
• For all materials of medium and high hardness
• For use with diamond grain size: 3/1 µm
• Fixation system: Magnetic foil

GALAXY – OMEGA
• Suitable for fine polishing with fine polishing suspension
• Soft synthetic cloth (chemical resistant)
•, For all materials
•, Suitable for oxide suspensions
• Fixation system: Magnetic foil

ALPHA – Polishing cloth
• Suitable for pre-polishing
• Very hard, perforated chemical fiber cloth
• For ceramics, hard metal, steel, grey cast iron, aluminum
• High lifetime and stock removal
• For use with diamond grain size: 15/9 µm
• Fixation system: X-Tap

DELTA – Polishing cloth
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, plastics [CFK, GFK], coatings, aluminum
• For use with diamond grain size: 9/6/3 µm
• Fixation system: X-Tap

GAMMA – Polishing cloth
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, coatings, plastics [CFK, GFK],
• For use with diamond grain size: 9/6/3 µm
• Fixation system: X-Tap

PHI – Polishing cloth
• Suitable for pre-, intermediate-, and end polishing
• Medium hard chemical fiber cloth
• For iron, non – ferrous metals, minerals, ceramics, composite materials
• For use with diamond grain size: 9/6/3/1 µm
• Fixation system: X-Tap

SIGMA – Polishing cloth
• Suitable for pre- & intermediate polishing
• Soft wool cloth
• For all materials
• For use with diamond grain size: 6/3/1 µm
• Fixation system: X-Tap

ETA – Polishing cloth
• Suitable for end polishing
• Short flocked, medium hard synthetic cloth
• For all materials of medium and high hardness
• For use with diamond grain size: 3/1 µm
• Fixation system: X-Tap

KAPPA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Soft polishing felt
• For all materials
• Suitable for alumina
• Fixation system: X-Tap

OMEGA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Soft synthetic cloth (chemical resistant)
• For all materials
• Suitable for oxide suspensions
• Fixation system: X-Tap

LAMBDA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Brushed, structured synthetic cloth (chemical resistant)
• For all materials
• Suitable for oxide suspensions as well as alumina
• Fixation system: X-Tap

Filter inserts for settling tank
(until year of construction 2012)

Filter inserts for settling tank
(from year of construction 2013)
